IRF530NPBF

Power MOSFET, TO-220, 12 A, ± 20 V, Advanced Process Technology, Ultra Low On-Resistance

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.19~0.40 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.19~0.40

PartNumber:: IRF530NPBF

Brand:: International Rectifier - IR | Pack: TO | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Hong's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-12-13

From Other Seller

Part Number:IRF530NPBF
US $0.19 - 0.40
74AHC2G08VS SOP-8

US $2.00 - 2.00 / Piece
(0) Remove
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The IRF530NPBF is a Power MOSFET from International Rectifier. The IRF530NPBF utilizes advanced processing techniques to achieve extremely low on-resistance per silicon area. This benefit, combined with the fast switching speed and ruggedized device design that HEXFET power MOSFETs are well known for, provides the designer with an extremely efficient and reliable device for use in a wide variety of applications.

Parametrics

IRF530NPBF absolute maximum ratings: (1)ID @ TC = 25℃, Continuous Drain Current, VGS @ 10V: 17A; (2)ID @ TC = 100℃, Continuous Drain Current, VGS @ 10V: 12 A; (3)IDM, Pulsed Drain Current: 60A; (4)PD @TC = 25℃, Power Dissipation: 70 W; (5)Linear Derating Factor: 0.47 W/℃; (6)VGS, Gate-to-Source Voltage: ± 20 V; (7)IAR, Avalanche Current: 9.0 A; (8)EAR, Repetitive Avalanche Energy: 7.0 mJ; (9)dv/dt, Peak Diode Recovery dv/dt: 7.4 V/ns; (10)TJ,TSTG, Operating Junction and Storage Temperature Range: -55 to + 175℃; (11)Soldering Temperature, for 10 seconds: 300℃ (1.6mm from case ); (12)Mounting torque, 6-32 or M3 srew: 1.1Nm.

Features

IRF530NPBF features: (1)Advanced Process Technology; (2)Ultra Low On-Resistance; (3)Dynamic dv/dt Rating; (4)175℃ Operating Temperature; (5)Fast Switching; (6)Fully Avalanche Rated.
