LM2596T-5.0

LM2596T-5.0, 5V, 3A, 150 kHz, TO220-5, step-down voltage regulator

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.71~0.79 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.71~0.79

PartNumber:: LM2596T-5.0

Brand:: National Semiconductor - NS | Pack: TO | D/C: 06+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Hong's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-20

From Other Seller

Part Number:LM2596T-5.0
US $0.71 - 0.79
AT25256AW-10SU-2.7

US $0.65 - 1.50 / Piece
(0) Remove
FM31256-G

US $2.40 - 4.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LM2596T-5.0 is a step-down voltage regulator, provides all the active functions for a step-down(buck) switching regulator, capable of driving a 3A load with excellent line and load regulation. This device in fixed output voltages of 3.3V, 5V, 12V, and an adjust-able output version. The applications of the LM2596T-5.0 include simple high-efficiency step-down (buck) regulator, on-card switching regulators, positive to negative converter.

Parametrics

LM2596T-5.0 absolute maximum ratings: (1)Maximum supply voltage: 45V; (2)ON /OFF pin input voltage: －0.3≤ V ≤ +25V; (3)Feedback pin voltage: －0.3≤ V ≤ +25V; (4)Output voltage to ground(steady state): －1V; (5)Power dissipation: internally limited; (6)Storage temperature range: －65℃ to +150℃.

Features

LM2596T-5.0 features: (1)3.3V, 5V, 12V, and adjustable output versions; (2)Adjustable version output voltage range, 1.2V to 37V±4% max over line and load conditions; (3)Available in TO-220 and TO-263 packages; (4)Guaranteed 3A output load current; (5)Input voltage range up to 40V; (6)Requires only 4 external components; (7)Excellent line and load regulation specifications; (8)150 kHz fixed frequency internal oscillator; (9)TTL shutdown capability; (10)Low power standby mode, IQ typically 80 μA; (11)High efficiency; (12)Uses readily available standard inductors; (13)Thermal shutdown and current limit protection.
