Product Summary

The ADS8322Y/250 is a 16-bit, 500kHz Analog-to-Digital (A/D) converter with an internal 2.5V reference. The device includes a 16-bit capacitor-based Successive Approximation Register (SAR) A/D converter with inherent sample-and-hold. The ADS8322Y/250 offers a full 16-bit interface, or an 8-bit option where data is read using two read cycles and 8 pins. The ADS8322 is available in a TQFP-32 package and is guaranteed over the industrial –40℃ to +85℃ temperature range. The applications of the ADS8322Y/250 include ct scanners, high speed data acquisition, test and instrumentation and medical equipment.

Parametrics

ADS8322Y/250 absolute maximum ratings: (1)+IN to GND: VA + 0.1V; (2)–IN to GND: +0.5V; (3)VA to GND: –0.3V to +7V; (4)Digital Input Voltage to GND: –0.3V to (VA + 0.3V); (5)VOUT to GND: –0.3V to (VA + 0.3V); (6)Operating Temperature Range:–40 to +105℃; (7)Storage Temperature Range: –65 to +150℃; (8)Junction Temperature (TJ max): +150℃; (9)Power Dissipation: (TJ max – TA)/θJA; (10)θJA Thermal Impedance: 240℃/W; (11)Lead Temperature: Vapor Phase (soldering, 60s): +215℃; Infrared (soldering, 15s): +220℃.

Features

ADS8322Y/250 features: (1)high-speed parallel interface; (2)500kHz sampling rate; (3)low power: 85mW at 500kHz; (4)internal 2.5V reference; (5)unipolar input range; (6)TQFP-32 package.

Diagrams

ADS8322Y/250 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
ADS8322Y/250
ADS8322Y/250
Texas Instruments
ADC (A/D Converters) Unipolar 16-Bit 500kSPS CMOS
Data Sheet
0-1: $12.16
1-10: $11.07
10-25: $10.23
25-50: $9.88
ADS8322Y/250G4
ADS8322Y/250G4
Texas Instruments
ADC (A/D Converters) Unipolar 16B 500kSPS CMOS ADC
Data Sheet
0-187: $7.43
187-250: $7.33
250-500: $7.19
500-750: $7.05
