Product Summary
The 4N26 is a general purpose 6-pin phototransistor optocoupler. It consists of a gallium arsenide infrared emitting diode driving a silicon phototransistor in a 6-pin dual in-line package. The applications of the 4N26 include Power supply regulators, Digital logic inputs, Microprocessor inputs.
Parametrics
4N26 absolute maximum ratings: (1)Storage Temperature: -55 to +150 ℃; (2)Operating Temperature: -55 to +100 ℃; (3)Wave solder temperature: 260 ℃ for 10 sec; (4)Total Device Power Dissipation @ TA = 25℃: 250 ℃; (5)Derate above 25℃: 3.3 (non-M), 2.94 (-M) mW; (6)DC/Average Forward Input Current: 100 (non-M), 60 (-M) mA; (7)Reverse Input Voltage: 6 V; (8)Forward Current - Peak (300μs, 2% Duty Cycle): 3 A; (9)LED Power Dissipation @ TA = 25℃: 150 (non-M), 120 (-M) mW; (10)Derate above 25℃: 2.0 (non-M), 1.41 (-M) mW/℃.
Features
4N26 features: (1)Also available in white package by specifying -M suffix, eg. 4N25-M; (2)UL recognized (File # E90700); (3)VDE recognized (File # 94766): Add option V for white package (e.g., 4N25V-M), Add option 300 for black package (e.g., 4N25.300).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 4N26 |
Vishay Semiconductors |
Transistor Output Optocouplers Phototransistor Out |
Data Sheet |
|
|
||||||||||||
 |
4N26(SHORT) |
|
PHOTOCOUPLER TRANS OUT 6-DIP |
Data Sheet |
Negotiable |
|
||||||||||||
|
4N26(SHORT,F) |
Toshiba |
Transistor Output Optocouplers RECOMMEND 4N25SHORT |
Data Sheet |
|
|
||||||||||||
|
4N26_Q |
Fairchild Semiconductor |
Transistor Output Optocouplers DIP-6 PHOTO TRANS |
Data Sheet |
Negotiable |
|
||||||||||||
|
4N26300 |
Fairchild Semiconductor |
Transistor Output Optocouplers Optocoupler Phototransistor |
Data Sheet |
|
|
||||||||||||
|
4N26300W |
Fairchild Semiconductor |
Transistor Output Optocouplers Optocoupler Phototransistor |
Data Sheet |
Negotiable |
|
||||||||||||
|
4N263S |
Fairchild Semiconductor |
Transistor Output Optocouplers Optocoupler SM-DIP6 Phototransistor |
Data Sheet |
Negotiable |
|
||||||||||||
|
4N263SD |
Fairchild Semiconductor |
Transistor Output Optocouplers Optocoupler SM-DIP6 Phototransistor |
Data Sheet |
Negotiable |
|
||||||||||||
