Product Summary
The LM3S6911-IQC50-A2 microcontroller is targeted for industrial applications, including remote monitoring, electronic point-of-sale machines, test and measurement equipment, network appliances and switches, factory automation, HVAC and building control, gaming equipment, motion control, medical instrumentation, and fire and security. For applications requiring extreme conservation of power, the LM3S6911-IQC50-A2 microcontroller features a battery-backed Hibernation module to efficiently power down the LM3S6911-IQC50-A2 to a low-power state during extended periods of inactivity. With a power-up/power-down sequencer, a continuous time counter (RTC), a pair of match registers, an APB interface to the system bus, and dedicated non-volatile memory, the Hibernation module positions the LM3S6911-IQC50-A2 microcontroller perfectly for battery applications.
Parametrics
LM3S6911-IQC50-A2 absolute maximum ratings: (1)VESDHBM: 2.0 kV; (2)VESDCDM: 1.0 kV; (3)VESDMM: 100 V.
Features
LM3S6911-IQC50-A2 features: (1)50-MHz operation; (2)Hardware-division and single-cycle-multiplication; (3)Integrated Nested Vectored Interrupt Controller (NVIC) providing deterministic interrupt handling; (4)30 interrupts with eight priority levels; (5)Memory protection unit (MPU), providing a privileged mode for protected operating system functionality; (6)Unaligned data access, enabling data to be efficiently packed into memory; (7)Atomic bit manipulation (bit-banding), delivering maximum memory utilization and streamlined peripheral control.
Diagrams
<IMG border=0 alt="LM3S6911-IQC50-A2 block diagram" src="http://www.seekic.com/uploadfile/ic-mfg/201282703447776.jpg">
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LM3S6911-IQC50-A2 |
Texas Instruments |
ARM Microcontrollers (MCU) LM3S6911 |
Data Sheet |
|
|
||||||||||||
|
LM3S6911-IQC50-A2T |
Texas Instruments |
ARM Microcontrollers (MCU) LM3S6911 |
Data Sheet |
|
|
||||||||||||
