Product Summary
The APM3020P is a P-Channel Enhancement Mode MOSFET. The applications of the device are Power Management in Notebook Computer, Portable Equipment and Battery Powered Systems.
Parametrics
APM3020P absolute maximum ratings: (1)Drain-Source Voltage: -30V; (2)Gate-Source Voltage: ±20V; (3)Maximum Drain Current – Continuous: -40A; (4)Maximum Drain Current – Pulsed: -70A; (5)Maximum Junction Temperature: 150 ℃; (6)Storage Temperature Range: -55 to 150 ℃; (7)Thermal Resistance – Junction to Case: 2.5 ℃/W.
Features
APM3020P features: (1)-30V/-11A, RDS(ON) = 17mΩ(typ.) @ VGS = -10V, RDS(ON) = 24mΩ(typ.) @ VGS = -5V; (2)Super High Density Cell Design; (3)Reliable and Rugged; (4)TO-252 Package.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 APM3020P |
Other |
|
Data Sheet |
Negotiable |
|
||||
|
APM3020PU |
Other |
|
Data Sheet |
Negotiable |
|
||||
